Hoymiles HYS-6.0LV-USG1 6.0kW Single-Phase DC Hybrid Solar Inverter | Battery Backup
$3,091.00
28 people are viewing this product right now
Hoymiles HYS-6.0LV-USG1 – smart on-grid hybrid inverter with 6kW output, dual MPPT, and backup power. Reliable solar and battery integration.
6kW Power Output, Dual MPPT Tracking, CEC Efficiency 97.0%, 150% DC/AC Ratio, 120/240V Battery Backup, Arc Fault Protection, Rapid Shutdown Safety, UL Listed.
Maximize your solar energy and ensure uninterrupted power with the Hoymiles HYS-6.0LV-USG1, a 6.0kW single-phase hybrid inverter. This on-grid hybrid inverter manages energy from your solar panels, the grid, and battery storage, optimizing efficiency and reducing electricity costs.
With MPPT tracking technology and a DC/AC ratio of up to 150%, it captures maximum solar energy even under variable sunlight conditions. The inverter provides 120/240V seamless backup power, keeping critical loads powered during outages without the need for an external autotransformer.
Safety and reliability are built in with integrated arc fault protection, rapid shutdown, and flexible load management via dry contacts. Fully compatible with the Hoymiles HBX-10.2LV-USG1 51.2V battery, it allows for efficient energy storage, smart load balancing, and reliable backup power.
Features such as real-time monitoring, remote management capabilities, and a peak efficiency of 97.6% make the Hoymiles DC hybrid inverter the ideal solution for smart, reliable, and high-performance solar energy management.
| Type | Single-phase hybrid storage inverter |
| Maximum Input Power | 9.0kW |
| Maximum PV Input Voltage | 550V |
| Nominal Input Voltage | 380V |
| MPPT Voltage Range | 125–500V |
| Maximum Input Current | 16/16A |
| Number of MPPTs | 2 |
| Number of Inputs per MPPT | 1 |
| Nominal Battery Voltage | 48V |
| Battery Voltage Range | 40–60V |
| Max. Charge/Discharge Current | 100/100A |
| Max. Output Power (On-Grid) | 6.0kW |
| Max. Output Current (On-Grid) | 25A |
| Max. Input Current (On-Grid) | 50A |
| Max. Output Apparent Power (Off-Grid) | 6.0kW |
| Nominal AC Voltage (Off-Grid) | 120/240V (Split-phase) |
| Max. Continuous Output Current (Off-Grid) | 25A |
| CEC Peak Efficiency | 97.0% |
| Max. Efficiency | 97.6% |
| Mounting | Wall Mounting |
| Protection Degree | Type 4X |
| Max. Parallel Units | 10 |
| Warranty | 10 Years |
| Weight | 68.3 lbs |
|---|---|
| Dimensions | 23.6 × 19.8 × 7.95 in |
| MPN | HYS-6.0LV-USG1 |
