Liniotech 10 kWh LiFePO₄ Lithium Iron Battery | Wall Battery Storage | Residential ESS Power System
$2,864.99
31 people are viewing this product right now
Store solar energy safely and efficiently with the Liniotech 10 kWh LiFePO₄ Wall Battery. Modular, expandable to 160 kWh, app-controlled, and built with CATL technology.
The Liniotech 10 kWh LiFePO₄ Lithium Iron Battery delivers safe, efficient, and expandable home energy storage solution. Built with CATL lithium-iron-phosphate (LiFePO₄) cells — the same technology trusted in leading EVs — this home energy storage solution offers exceptional safety, reliability, and a 20-year lifespan.
Designed for homes, small businesses, and off-grid systems, this power wall battery storage stores excess solar energy during the day and releases it when needed — reducing your dependence on the grid and keeping your home powered during outages. Its modular design allows you to combine up to 16 units for a total of 160 kWh of usable power, ideal for both single-phase and large-scale setups.
Simple to install, easy to maintain, and compatible with all major inverter brands, the Liniotech 10 kWh Lithium Iron Battery gives you complete control of your energy future.
Key Features of Liniotech 10kWh LiFePO₄ Home Battery Backup
Expandable Power Capacity – Connect up to 16 batteries for a massive 160 kWh energy storage system.
Advanced LiFePO₄ Technology – Safe, stable chemistry with over 8500 cycles and 20-year design life.
CATL Battery Cells & BMS – First-class reliability from the world’s leading EV battery manufacturer.
Modular & Wall-Mounted Design – Compact form factor for quick installation and easy maintenance.
Smart Monitoring App – Real-time performance tracking, charge status, and remote diagnostics.
All-In-One Residential ESS – Integrates with any solar panel system and most inverter brands.
Universal Inverter Compatibility – Works with Sol-Ark, Deye, Goodwe, SMA, Victron, Growatt, Lux Power, and more.
High Safety Standards – Certified to IEC 62619, UN38.3, CE-EMC, with UL 1973 / UL 9540A pending.
Wide Operating Range – Reliable performance from -20 °C to 60 °C, indoor or outdoor use (IP21).
Long-Term Assurance – Backed by a 12-year warranty and full technical support.
| Model | LINIOTECH 10 |
| Battery Type | LiFePO₄ |
| Nominal Voltage | 51.2 V |
| Nominal Capacity | 200 Ah |
| Usable Energy | 10.24 kWh |
| Max. Charge/Discharge Current | 150 A (7.68 kW) |
| Cycle Life (80% DOD, 25 °C) | 8,500 cycles |
| Cooling Method | Natural |
| Ingress Protection | IP21 |
| Operating Temp. | -20 °C to 60 °C |
| Communication | RS485 / CAN / App |
| Certifications | IEC 62619, CE-EMC, UN38.3 (UL pending) |
| Warranty | 12 Years |
| Weight | 216 lbs |
|---|---|
| Dimensions | 20.7 × 28.9 × 7.4 in |
| MPN | LINIOTECH10-1 |
