SMA SUNNY HIGHPOWER PEAK3 3-150-1500-2-21 150.0KW 3-PH INVERTER

SMA, Sunny Highpower, Peak3, 3-Ph Grid Tied Utility Inverter, 150kW, 600Vac, 50/60Hz, 1500Vdc input, 1 MPPT, 5 Yr. Warr, Transformerless, No Disconnects or AFCI, SHP 150-US-21, 3-150-1500-2-21

PEAK 3 stands for pure power. With its compact design, the inverter offers maximum power density at minimum weight. This results in less expensive transportation and simplified installation. In combination with the project-specific DC Combiner Boxes, the PV array can be oversized up to 200 %. The Data Manager powered by ennexOS completes the system and enables it to fulfill all of the grid operator’s requirements.

The Sunny Highpower PEAK3 150-US-21 is the 600 VAC model of SMA’s 1,500 VDC PEAK3 platform, built for large commercial and utility-scale ground-mount projects.

Availability: Incoming — 1 unit scheduled to arrive in December. Limited availability. Contact CSE to confirm availability, delivery timing and freight. Freight is quoted separately.

Specifications (SMA datasheet SHP-US-DS-en-23, type SHP 150-US-21)

• Manufacturer part number: 3-150-1500-2-21
• Max. AC power: 150 kW / 150 kVA
• Nominal AC voltage: 600 V, 3-phase
• Max. DC voltage: 1,500 V
• MPP trackers: 1
• Max. array power: 300 kWp
• Weight: 99 kg / 218 lb
• Device dimensions (W × H × D): 770 × 830 × 462 mm / 30.3 × 32.7 × 18.2 in
• Grid standards: IEEE 1547:2018, UL 1741 SA and SB, CA Rule 21, HECO 14H
• Standard warranty: 5 years
