Q Cells Q.Peak DUO BLK ML G10+ 400-12 400W Solar Panel

QCells, 400W PV Module, MC4, PV Wire ~49.2” (1250mm), 32mm Black Frame/Black Sheet, BOB, 132 Cell 12 BB Mono, 20A Fuse, 1000Vdc, 371.5 PTC, 25/25 Warranty, Q.PEAK DUO BLK ML G10+ 400-12

Q CELLS Q.PEAK DUO BLK ML-G10+400 is an all-black solar panel ideal for residential PV systems. The new Q.ANTUM DUO Z technology eliminates the gap between cells, allowing for a panel efficiency above 20%. The monocrystalline cell technology protects against hot spots and guarantees performance under any weather condition. The aluminum alloy frame of the Q CELLS solar panels is certified for high snow (5400 Pa) and wind loads (4000 Pa) according to IEC/UL standards. Q-Cells panels come with an inclusive 25-year product warranty and a 25-year linear performance warranty.

Q CELLS Q.PEAK DUO BLK ML-G10+400 Specifications

Nominal Power: 400W
Efficiency: 20.4 %
Maximum System Voltage: 1000 V
Wind/Snow Load: 4000 / 5400
Dimensions Including Frame: 74.0 x 41.1 x 1.26 in (1879 × 1045 × 32 mm)
Weight: 48.5 lbs (22.0 kg)

Short Circuit Current Isc: 11.14A
Open Circuit Voltage Voc: 45.30V
Current at MPP Imp: 10.77A
Voltage at MPP Vmp: 37.13V

Warranty Information

At least 98 % of nominal power during the first year. After that, max. 0.54 % degradation per year. At least 93.1 % of nominal power up to 10 years. At least 85 % of nominal power up to 25 years.
