Seraphim SRP-595-BTA-BG Sable 595W N-Type TOPCon Bifacial Solar Panel – Pallet Pricing (36 Panels | 21.42kW) – New Jersey Pickup
Original price was: $6,499.00.$6,449.00Current price is: $6,449.00.
34 people are viewing this product right now
Seraphim SRP-595-BTA-BG 595W solar panel pallet, New Jersey pickup: 36 Sable Series N-type TOPCon bifacial modules (21.42 kW DC), 23.03% efficiency, 1500 V, 1000 mm cables with MC4-compatible connectors. Full pallet only, EXW New Jersey, freight quoted. Same module as the standard lot, different cable length and pickup point.
This listing is the New Jersey lot of the Seraphim SRP-595-BTA-BG 595W solar panel pallet. The module is identical to the standard SRP-595-BTA-BG pallet: 144 half-cut N-type 182 mm TOPCon cells, dual 2.0 mm glass, 595 W at STC, 23.03% efficiency, 0 / +4.99 W tolerance and 652 W under the datasheet’s bifacial nameplate condition. Two things differ, and both are verified from Seraphim’s quotation: the modules in this lot are supplied with 1000 mm output cables and MC4-compatible connectors, and the pallets are picked up in New Jersey.
Why the cable length matters. Seraphim’s standard configuration for this model is 250 mm positive / 350 mm negative leads. The 1000 mm leads on this lot reach further between modules, which some racking layouts prefer and others do not need; check the cable length against your design before ordering, and choose the standard lot if the shorter leads suit it better.
Who buys this lot. Contractors in New Jersey, New York, Pennsylvania and the wider Northeast who want a full 21.42 kW DC pallet close to the job site. Pickup is at a CSE-controlled location in New Jersey; freight to other states is quoted on request. Availability is confirmed when you submit an order request.
Related Seraphim pallets: the SRP-580-BTA-BG 580W New Jersey lot (also New Jersey pickup, 320 / 260 mm cables), the SRP-590-BTA-BG 590W pallet and the Seraphim brand page for every model CSE carries.
Ordering and warranty. Full pallet only (36 panels). Pallet price is EXW New Jersey; freight quoted separately; no online payment. Seraphim’s 30-year linear power output warranty applies: ≤1% degradation in year one, ≤0.4% per year after that, ≥87.4% output at year 30. Datasheet, warranty and installation manual are linked under Documents & Downloads.
Specifications (Seraphim datasheet SRP-DS-EN-2026V1.4 USA)
| Maximum power Pmp (STC) | 595 W |
|---|---|
| Module efficiency | 23.03% |
| Voc / Isc (STC) | 52.70 V / 14.25 A |
| Vmp / Imp (STC) | 44.00 V / 13.54 A |
| BNPI (rear 135 W/m²) | 652 W |
| Cells | 144 × N-type 182 mm TOPCon, half-cut |
| Construction | Bifacial dual glass, 2.0 mm + 2.0 mm AR-coated semi-tempered low-iron glass |
| Frame | Anodized aluminium alloy |
| Dimensions | 2278 × 1134 × 30 mm (89.69 × 44.65 × 1.18 in) |
| Weight | 32.0 kg (70.5 lb) |
| Max system voltage / fuse | 1500 V DC / 25 A |
| Temperature coefficients | Pmax −0.29 %/°C, Voc −0.25 %/°C, Isc +0.046 %/°C |
| NOCT / operating range | 45 ± 2 °C / −40 to +85 °C |
| Bifaciality | 80% ± 5% |
| Mechanical load | 5400 Pa front / 2400 Pa rear |
| Fire performance | Type 29 |
| Junction box | IP68, 3 bypass diodes |
| Power tolerance | 0 / +4.99 W |
| Certification marks (datasheet) | TÜV, CE, CSA-US (cCSAus), PV Cycle |
| Warranty | 30-year linear power output warranty (≥87.4% at year 30) |
| Datasheet | Seraphim SRP-(575-600)-BTA-BG_182, SRP-DS-EN-2026V1.4 USA |
| Cables | 4.0 mm², 1000 mm (New Jersey lot) |
| Panels per pallet | 36 (full pallet only) |
| Total pallet power | 21.42 kW |
| Pickup | New Jersey (CSE-controlled pickup location) |
Documents & Downloads
Download Product Datasheet (PDF) Download Manufacturer Warranty (PDF) Download Installation Manual (PDF)
Pallet ordering
Sold by the full pallet only. Prices are per pallet, EXW a CSE-controlled pickup location; freight is quoted separately. Submit an order request and our team confirms availability, pickup point and freight before any payment is due.
| Weight | 32.0 lbs |
|---|---|
| Dimensions | 227.8 × 113.4 × 3.0 in |
| Brand | Seraphim |
| Series | Sable |
| MPN | SRP-595-BTA-BG |
| Wattage | 595 W |
| Cell technology | N-type TOPCon |
| Bifacial | Yes |
| Glass | Dual glass |
| Cells | 144 |
| Panels per pallet | 36 |
| Pallet kW | 21.42 |
| Frame color | Silver |
| Dimensions | 2278 × 1134 × 30 mm |
| Weight | 32.0 kg |
| Max system voltage | 1500 V |
| Efficiency | 23.03% |
| Warranty | 30-year linear power |
| Pickup | New Jersey |
